- WXGA,IPS Color LCD Touch Screen
- Shows 16,777,216 colors
- Measures 10.1' diagonally
- Displays Clock and Date
- Mpeg-4 movie/video play function
- Video display size 6.2' diagonally
- Exclusive 1GB Memory Storage for video
- NeedleCam™ Digital Camera for embroidery and sewing positioning with faster scanning, 3X higher resolution
- Precise Touch Positioning™ using NeedleCam
- IQ Designer with paper holding frame for image scanning
- LCD screen size can be enlarged to 1280 x 800 pixels
- Will automatically create an embroidery pattern from a JPEG image
- Drawing area is 3-3/4' x 5-11/16' (96mm x 145mm)
- 90 Preloaded open, closed and region shapes
- Able to select different line colors and fill colors
- 6 Different stitch patterns: running, bean, satin and no outline
- 13 Different fill patterns: regular fill, no fill, Stipple inside or around a shape and 10 decorative pattern fills
- Duplicate, paste and edit preloaded shapes
- Adjust line, fill and stippling width, length and density properties
- Undersewing options
- Outline stamp shape creation for Trapunto techniques
- Fine- For illustrations
- Standard - For line drawings
- Guide Beam and Needle Beam for precision alignment of stitches
- Class 1 Laser Product (IEC60825-1:2007)
- Sensor Pen allows you to set preferences
- Set a guideline for sewing
- Select the needle position location
- Select custom zigzag widths
- Choose an ending point on the fabric for stitches to stop sewing
- See the needle position location for embroidery
- Select precise placement for embroidery designs
- Color Visualizer with pinnable color selections
- Enhanced Stadium Lighting for 50% brighter true color LED lighting on the needle and work area with 5 settings
- 3 USB drives
- 2 (Type A) USB 2.0 drives to connect a mouse Flash drives, Hub and CD-ROM drives
- 1 (Type B) USB direct connect to a PC
- Precise tracking system on embroidery carriage
- LED spool stand lighting
- External speaker jack and adjustable volume settings
- NeverMiss™ Automatic Advanced Threading System
- Digital Dual-Feed System ensures utmost fabric control when feeding layers or difficult fabric types
- Digital Dual-Feed couching sole for decorative stitching and reverse bobbinwork
- Advanced Pivoting Feature and Automatic Fabric Sensor System
- Automatic sensors
- Thread tension control makes tension adjustments for accurate stitches
- Upper and lower thread sensors on/off
- Upper and lower thread sensors to alert when threads run out
- On-screen hoop sensor to recommend size of hoop
- Embroidery and sewing speed up to 1,050 spm
- Resume mode
- Programmable shutoff capabilites
- Eco power mode
| Embroidery Capabilities • 661 Embroidery designs built-in including:
- 336 Baby Lock exclusives
- 37 Nancy Zieman designs
- 15 Buttonhole embroidery designs in 3 sizes (45 total)
- 15 Buttonhole embroidery frame designs
- 160 Large decorative stitch designs
- 14 Sophisticated bobbin work embroidery designs
• 140 Frame combinations
• 28 Font styles including:
- Extra-large striped alphabet and characters (100 total)
- Extra-large block alphabet and characters (100 total)
- Exclusive script alphabet and characters (70 total)
- Large floral block alphabet (64 total)
- Large vine alphabet (30 total)
- Greek alphabet (24 total)
• Embroiders up to 9.5' x 14' (240mm x 360mm)
embroidery field
• Memory capacity approximately 9MB
• Reads embroidery designs with a stitch capacity of up to
700,000 stitches per design
• WXGA, IPS Color LCD Touch Screen shows
- Design placement using drag/drop and slide/ scroll
capabilities
- Enhanced Realistic Preview
- Design previews can be enlarged 200%
- Needle positioning grid selections
- Needle position image can be enlarged 200%
- Estimated embroidery time display and stitch count
- Needle advancement (1, 10, 100, or 1000 stitch
increments)
- Measurements displayed in inches or metrics
- Color separation
- Thread color indicator
- On-screen hoop size indicator including 9.5' x 9.5' hoop
- Low bobbin thread indicator
- 300 color names
- Screen saver customization
- Thumbnail images viewed at 150% the normal size
• Embroidery speed up to 1,050 spm
• 9-Point trial check points
• Starting point key for instant alignment of characters or
patterns
• Alternate bobbin case for pre-wound bobbins
- Combine embroidery designs on screen
- Character/text array function
- Character spacing
- 0.1°, 1°, 10°, and 90° pattern rotation
- Enhanced design enlargement (up to 200%) and reduction (down to 60%) capabilities
- Design duplication
- Automatic appliquê
- Automatic basting
- Mirror imaging
- Change color selections within designs
- Color sorting on border designs
- Monochrome option for embroidery designs
- Programmable custom thread color selection
|
Advanced Sewing Features - 770 Built-in stitches including
- 149 Utility including 15 one-step buttonhole styles and 1 four-step custom buttonhole
- 442 Decorative
- 79 Decorative satin
- 20 Satin
- 17 Cross
- 63 Combinable Utility stitches
- 5 Built-in alphabets
- 30 Quilting stitches offer 57 needle position options
- Stitch length 0.0mm - 5.0mm
- Basting stitch length of up to 30mm
- Maximum Utility stitch width 7mm
- Utility stitch editing capabilities
- 5 Memory settings for each Utility stitch
- Decorative stitch editing capabilities
- Edit and combine Character Decorative stitches
- Character/Decorative stitch memory equaling 1MB
- Satin stitch elongation
- Edge sewing capabilities using NeedleCam Digital Camera
- Sew Utility and Decorative stitches while embroidery arm is attached
- Automatic drop feed on screen
- Mirror-image
- Lock key for Utility and Decorative stitches
- Reinforcement priority settings
- Lateral and diagonal feeding
- Variable needle positions
- Fully automatic built-in darning
- Twin needle settings
- Larger sewing bed and workspace with 11.25' to the right of the needle
- Convenient one-touch buttons for
- Start/Stop
- Reverse sewing
- Reinforcement key
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Automatic needle threading
| Instructional and Help Resources - Built-in Operational Guide with up to 43 help topics and built-in videos
- Built-in Sewing Application Guide
- Built-in Help Messages
- Embroidery Stitch Count System - SCS
- Capability to save settings screen images
Downloadable Software- Your Destiny will stay current with future upgrades via USB connection
Additional Information- Language conversion capabilities (12 languages)
- Warranty (25 years limited, 10 years parts, 5 years computer circuit, 5 years electrical, 1 year labor)
- Optional Love of Sewing Membership
- Optional embroidery hoops
- 6-1/4' x 10-1/4' (160mm x 260mm) hoop
- 8' x 8' (200mm x 200mm) hoop
- 1' x 2-1/2' (20mm x 60mm) hoop
- Continuous Border Hoop 4' x 7' (100mm X 180mm) (BLSO-BF)
- Continuous Border Hoop 4' x 12' (100mm X 300mm) (BLMA-CBH)
- Baby Lock digital USB mouse
- Optional thread stand (holds 10 spools) (BLMA-TS)
- Optional extension table (BLMA-ET)
- Optional embroidery card Reader (BLECR)
- Quick-Set, Top-Loading bobbin with sensor
- Quick-Set Independent bobbin winding system with variable speed
- Ergonomic 3-position, adjustable knee lift with extra high presser foot lift
- 10mm Automatic and 13mm Manual
- Programmable 3-step needle up/down
- Automatic thread cutter (with on/off capability)
- Needle plate with scale in inches and centimeters
- Multi-Function Foot Control
- Free arm
- Two accessory storage compartments
|
Included Accessories - Sensor Pen and Holder
- Adjustable knee lifter with 3-position handle
- Touch pen (stylus)
- LCD cleaning cloth
- USB cable
- 16 Snap-on presser feet
- Digital Dual-Feed System Foot
- Couching sole for Digital Dual-Feed
- Embroidery foot with LED pointer
- General purpose zigzag
- Blind stitch
- Buttonhole
- Button fitting
- Free-motion open toe quilting
- Free-motion quilting
- Free-motion echo
- Monogramming
- Overcasting
- 1/4' Quilting foot with a guide
- Straight stitch foot
- Vertical stitch alignment foot
- Zipper
- Easy-lock accessory case for presser foot storage with interchangeable trays
- Multi-Function Foot Control
- Soft canvas cover for machine with 3 storage pockets
| - 2 Thread spool stand for larger cones
- Yarn guide and yarn threader
- Straight stitch needle plate
- Bobbin case and cover for embroidery and sewing bobbin work
- Alternate bobbin case for use with pre-wound bobbins
- Cord guide bobbin cover
- Bobbin center pin
- Embroidery bobbin thread
- Bobbins
- Embroidery Positioning Stickers (4-Sheets of 64)
- White needle calibration stickers
- 6 Edge sewing sheets
- Multi-position screwdriver
- Presser foot adaptor
- Seam ripper
- Twin needle
- Embroidery hoops and grids included
- 9.5' x 14' (240mm x 360mm)
- 8' x 12' (200mm x 300mm)
- 5' x 7' (130mm x 180mm)
- 4' x 4' (100mm x 100mm) |
Babylock Accent Embroidery Machine Manual Pdf
Youtube Babylock Machine Embroidery Tutorials
Technology Features- LCD Touch Screen (240 x 320 dot matrix) with touch pen
- USB direct connect (Type B)
- Embroidery card slot
- Advanced needle threader
- Automatic thread cutter
- Quick-Set, top loading bobbin with sensor
- Quick-Set bobbin winder
- Independent bobbin winding system
- Automatic sensors
- Thread tension control makes adjustments to feed thread properly
- Upper and lower thread sensors to alert when threads are broken
- On-screen hoop sensor to recommend size of hoop to use
Convenient Sewing Features- Convenient One-Touch Buttons for:
- Start/Stop
- Reverse sewing
- Needle up/down
- Thread cutter
- Automatic presser foot lift
- Low bobbin thread indicator
- Needle plate with scale in inches and centimeters
- Large sewing surface 12 1/4' x 8 1/8'
- Electronic foot control with separate power cord
- Free arm with drop feed lever
- Carrying handle
- Hard plastic cover case
- Two accessory storage compartments
- Programmable needle up/down
- Sewing Speed up to 1,000 spm
- Snap-on presser feet
Advanced Sewing Features- 313 Built-in stitches including 105 Utility with 12 one-step buttonhole styles; 57 combinable Utility stitches; 110 Decorative; 15 Wide satin; 14 Satin; 12 Cross
- Store personal stitch settings for each Utility stitch
- Decorative stitch editing capabilities
- Edit and combine Character Decorative
Stitches - 16 memory Pockets for Character/Decorative stitches equaling 224KB
- Stitch length 0.0mm - 5.0mm
- Mirror-image
- Maximum Utility stitch width: 7mm
- Lock key for Utility and Decorative stitches
- 5 LED lights that illuminate the needle and work area
- Ergonomic knee lift with extra high presser foot lift
- 10mm automatic and 13mm manual
- Lateral and diagonal feeding
- Variable needle positions
- 3 built-in alphabets
- Fully automatic built-in darning
- Twin needle settings
Included Accessories- Touch pen (stylus)
- Knee lifter
- USB cable
- 13 Feet
- Embroidery 'U'
- Buttonhole 'A'
- Overcasting 'G'
- Monogramming 'N'
- Zipper 'I'
- Zigzag 'J'
- Blind stitch 'R'
- Button fitting 'M'
- Cording (with 3 cord guide)
- Walking
- Blind stitch (with guide)
- Narrow hemmer
- Free-motion quilting
- Embroidery needle plate cover
- Alternate bobbin case (pink screw)
- Bobbin center pin (for prewound bobbin)
- Bobbins
- Embroidery bobbin thread
- Stabilizer
- Accessory scissors
- Seam ripper
- Needle set
- Twin needle
- Chalk pen
- Vertical spool pin
| Embroidery Capabilities- Embroidery design library built-in
- 158 Built-in embroidery designs including 86 Baby Lock exclusive designs
- 120 Frame combinations
- 9 font styles including one exclusive script
- Embroidery hoops and grids included
- Extra large 6 1/4' x 10 1/4' (160mm x 260mm)
- Large 5' x 7' (130mm x 180mm)
- Embroiders up to 6' x 10' (160mm x 260mm) embroidery field
- Up to 12 Memory Pockets for Embroidery and Embroidery Edit equaling 512KB/150,000 stitches
- Reads embroidery designs with a stitch capacity of up to 100,000 stitches per design
- LCD Touch Screen (240 x 320 dot matrix) shows
- Estimated embroidery time display and stitch count
- Needle position placement (1, 10, or 100 stitch increments)
- Measurements displayed in inches or millimeters (mm)
- Thread color indicator
- On-screen hoop size indicator
- Low bobbin thread indicator
- 300 color names
- Embroidery speeds up to 800 spm
- Data input types:
- 8-point trial check points
- Alternate bobbin case for prewound bobbins
Embroidery Editing Capabilities- Combine embroidery designs on screen
- Character/Text array function
- Character spacing
- 1°, 10°, and 90° Pattern rotation
- Design enlargement (up to 20%)
- Design reduction (up to 10%)
- Mirror imaging
Additional Information- Language conversion capabilities (13 languages)
- Warranty (25 years limited, 10 years parts, 5 years computer circuit, 5 years electrical, 1 year labor)
- Optional Gold Standard service and support program for your peace-of-mind (available in U.S.)
- Optional embroidery hoops
- Medium 4' x 4' (100mm x 100mm)
- Small 1' x 2.5' (20mm x 60mm)
- Machine Weight: 30 lbs (38 lbs with embroidery unit)
- Machine Height: 12'
- Machine Width: 20.13'
- Machine Depth: 10.13
- Needle to right of Machine distance: 13'
- Sewing Bed Width: 12.25'
- Sewing Surface height without table: 8.13'
Downloadable SoftwareYour Esante will stay current with future upgrades via USB connection.
Instructional and Help Resources- Built-in Operational Guide
- Built-in Sewing Application Guide
- Built-in Help Messages
|
